Apply Military grade security with SplitKey Cryptography

Customer Overview

iQabinet is a SaaS platform designed to simplify how individuals and families store, manage, and share sensitive personal documents with trusted professionals. From financial records and medical information to household utilities and institutional credentials, the platform centralizes high-value data and keeps users informed through secure sharing and real-time alerts. As a product built around deeply confidential information, enterprise data security sits at the core of iQabinet’s value proposition.

Project Overview

Given the sensitivity of the data iQabinet manages, the team required a security model strong enough that even if the underlying data were stolen, exposed, or accessed outside the platform, it would remain unreadable and impossible to decode. They decided to apply Split Key Cryptography, where each user’s data is encrypted with a private key that is locked by the user’s password and then split into two independent components. One part stays with the system, and the other is shared with the user, and neither piece can reveal or reconstruct the original key on its own. iQabinet partnered with TenUp to translate this design into a production-ready implementation that delivers uncompromising, end-to-end data security for every user.

Challenges

TenUp faced a series of cryptographic and usability challenges that required rethinking key management, strengthening data protection across two databases, and maintaining a seamless user experience without weakening security.

• Selecting the right cryptographic algorithm that delivers strong security without compromising performance for encrypting and decrypting high-volume user data by evaluating options like RSA and AES.
• Designing a secure mechanism to lock each user’s private key with their password and then split that password into two independent components, while ensuring the system-stored portion could never be compromised.
• Guaranteeing reliable and tamper-proof delivery of the user’s shareable key, since any loss or failed delivery would leave users unable to decrypt their own data.
• Improving the login experience so that users do not need to manually upload their shareable key during every authentication attempt, while still preserving the integrity of Split Key Cryptography.
• Creating centralized, cross-cutting cryptographic functions that automatically encrypt data on writes and decrypt it on reads across both MongoDB (storing unstructured data) and PostgreSQL (storing relational user information), removing the risk of developers handling encryption inconsistently.
• Ensuring secure storage and retrieval of highly sensitive documents such as financial statements and medical records, including preventing unauthorized access or downloads even if the underlying storage were compromised.

Solution

TenUp translated iQabinet’s Split Key Cryptography design into a production-grade military grade encryption software architecture, combining distributed credentials, hybrid RSA–AES encryption, controlled key delivery, and centralized cryptographic operations to ensure end-to-end protection across every data flow.

• Implemented a Split Key Cryptography model combining RSA and AES, using RSA only for private-key protection and AES for high-performance encryption/decryption of user data to maintain strong security without compromising speed.
• Generated an RSA private key for each user at registration, locked it with the user’s password, and created a unique 18-character AES secret encrypted with that private key for all subsequent cryptographic operations.
• Designed a distributed-credential mechanism that splits the user password into two mathematically independent components (shareable and non-shareable) and ensures the password cannot be reconstructed even if both strings are exposed.
• Secured the system-stored (non-shareable) component using a master private key protected by AWS KMS, keeping server-side credential fragments inaccessible to attackers.
• Built a controlled workflow forcing users to download their shareable key immediately after registration, with a timed deletion on the server and audit checks that block content creation until the key is successfully downloaded or regenerated.
• Strengthened login flows by validating username, password, and the user-held shareable key on every authentication event to preserve the integrity of Split Key Cryptography.
• Added a centralized cryptography layer that implicitly encrypts data on every write and decrypts it on every read across MongoDB, PostgreSQL, and S3, ensuring consistent protection without requiring developers to handle encryption logic.

Benefits

The Split Key Cryptography implementation strengthened iQabinet’s enterprise data security posture by providing protection comparable to military cryptography standards and unlocked meaningful business gains.

• Strengthened user confidence through end-to-end encryption of all stored data, backed by HTTPS-secured communication across the platform.
• Eliminated exposure risk even in breach scenarios because data cannot be decrypted without both password fragments, protecting the business from liability while ensuring uncompromised user privacy.
• Enabled the client to package and reuse the Split Key Cryptography implementation as an independent library, creating an additional value stream beyond the core product.

Technology

• RSA
• AES
• AWS KMS
• MongoDB
• PostgreSQL
• Amazon S3
• HTTPS/TLS
• Custom cryptography layer
• Mathematical splitting algorithm

Industry

• SaaS
